Power | Size | Lumi Flux | LED | Qty of leds | PF | CRI | Color | Input voltage |
3W | 28mm | 270lm | SMD2835 | 6pcs | >0.9 | >80 | Warm white/ Cold white | Direct to AC220V |
5W | 30mm | 450lm | SMD2835 | 10pcs | >0.9 | >80 | Warm white/ Cold white | Direct to AC220V |
7W | 35mm | 630lm | SMD2835 | 13pcs | >0.9 | >80 | Warm white/ Cold white | Direct to AC220V |
9W | 40mm | 810lm | SMD2835 | 20pcs | >0.9 | >80 | Warm white/ Cold white | Direct to AC220V |
12W | 44mm | 1080lm | SMD2835 | 24pcs | >0.9 | >80 | Warm white/ Cold white | Direct to AC220V |
15W | 44mm | 1350lm | SMD2835 | 22pcs | >0.9 | >80 | Warm white/Cold white | Direct to AC220V |
18W | 48mm | 1620lm | SMD2835 | 36pcs | >0.9 | >80 | Warm white/ Cold white | Direct to AC220V |
Material | aluminum plate base | |||||||
Dimmable | Dimming by PMW | |||||||
Warranty | 3 years | |||||||
Certificate | CCC CE and Roh | |||||||
Application | Widely use in ceiling light, downlight, indoor light, bulb light, dinner light etc | |||||||
Package include: 10pcs SMD2835 AC220V LED PCB Board
Notes :
1. Input AC170-275V,No need driver2. Integrated IC technology without electrolytic capacitors and transformers longer life3. Products are small, allowing more flexibility and more creative lighting design4. High power factor(>90%) and low total harmonic distortion easily through the EMC certification5. Power conversion efficiency overall program high light efficiency(>90lm/w)6. Suitable for dimmer dimming TRIAC dimming some electronic transfer7. Suitable bulb, candle lamps, downlights, ceiling lights
Application:
Widely used in Ceiling lighting, spotlight, Indoor Lighting, Special lighting,bulb light, tracking light,spotlight, floodlight, dinner lighting and so.
