Product Features : |
Before installing the lamp, please check whether there is ballast in the lamp holder. you bought the G23 G24-4 lamp holder, you have to choose the ballast inside the original lamp holder to remove, because the LED bulb is self-driven.If the ballast is not disassembled, the lamp will not work properly.Thank you 1.Environmentally Friendly,High CRI 2.High Efficient,Energy Saving 3.Long Life .Durability and Safe 4.Heat dissipation of aluminum shell 5.Lamp head 270 degree rotation 6.G23 transverse insertion lamp is installed on the desk lamp. Please remove the power of the lamp holder. |
|
Applications : |
Hotel ,Supermarket ,Home ,Counter ,Storesand types of indoor and decorative lighting. |
|
No. : |
Specifications : |
|
1 |
LED Type |
PL LED Bulb |
2 |
Power |
10W/12W/15W |
3 |
Lumen |
110LM/Watt |
4 |
Voltage |
85V-265V AC |
5 |
LED Quantity |
35/44/60 |
6 |
LED Chip |
COB |
7 |
Base Type |
E27/G24/G23/G24-4pins |
8 |
Color |
Warm White;Cold White |
9 |
Size(D*L) |
10W 35*125mm 12W 35*150mm 15W 35*170MM |
10 |
Color Temperature |
Warm white : 2800K-3200K ; Cold White : 6000K-6500K; |
11 |
Beam Angle |
180 degree |
12 |
Dimension |
(Picture Below) |
13 |
Color of Housing |
Silver |
14 |
CRI |
> 88 |
15 |
Case Material |
Aluminum+ Plastic |
16 |
IP Grade |
IP60 |
17 |
Working Frequency |
50 ~ 60HZ |
18 |
Working Temperature |
-40 degree ~ 60 degree |
19 |
LED Life |
> 50000 hours |
