Notes:
LED must be added with a radiator/cooling fan. Ensure that the wire and LED welding temperature is below 85 degrees!
Feature:
Purposes: to replace the downlight bulb, high power LED lights.
Type: aluminum plate welded lamp module.
Color: White(6000-6500K), Natural White(4000-4500), Warm
White(3000-3500)
Applications: indoor and outdoor lighting, road lamp, flashlight, lighting, spotlights, buried lights.
Details:
| Power |
Voltage |
Current |
LED Chips |
Size |
Luminous Flux |
| 2W |
DC 6-7V |
280-300mA |
4pcs |
Φ20mm |
55-60LM / LED |
| 3W |
DC 9-11V |
280-300mA |
6pcs |
Φ32mm |
55-60LM / LED |
| 5W |
DC 15-18V |
280-300mA |
10pcs |
Φ48mm |
55-60LM / LED |
| 7W |
DC 21-24V |
280-300mA |
14pcs |
Φ48mm |
55-60LM / LED |
| 9W |
DC 27-31V |
280-300mA |
18pcs |
Φ60mm |
55-60LM / LED |
| 12W |
DC 36V-41V |
280-300mA |
24pcs |
Φ70mm |
55-60LM / LED |
| 15W |
DC 45-51V |
280-300mA |
30pcs |
Φ85mm |
55-60LM / LED |
| 18W |
DC 54-62V |
280-300mA |
36pcs |
Φ85mm |
55-60LM / LED |
| 21W |
DC 63-72V |
280-300mA |
42pcs |
Φ110mm |
55-60LM / LED |
| 24W |
DC 72-82V |
280-300mA |
48pcs |
Φ100mm |
55-60LM / LED |
| 30W |
DC 90-102V |
280-300mA |
60pcs |
Φ112.8mm |
55-60LM / LED |
| 36W |
DC 108-123V |
280-300mA |
72pcs |
Φ112.8mm |
55-60LM / LED |
